Vss wire colour

[Thirsty2001]

Hello. Can anyone advise colour of vss wire? Thx Ross



[NQ94]

Guessing you are chasing the vehicle speed sensor wire. What are you using the VSS signal for?
Two places vehicle speed would come from would be the transmission from an internal OSS (VSS) and directly sent to the ZF 8HP (Pin C2) TCM within the transmission on the mechatronic unit or the wheel speed sensors to ABS/Traction ECU. Both would be sent to the dash and other ECUs by a CAN signal.



[parb]

Does anyone have a can bus diagram?
Is the can bus open or encrypted?
I'd like to see what is on the can bus, I'm a bit fan of the cantools package.

GitHub - cantools/cantools: CAN bus tools.

CAN bus tools. Contribute to cantools/cantools development by creating an account on GitHub.

github.com



[Thirsty2001]

Hello. Can anyone advise colour of vss wire? Thx Ross

Hello. I am looking to get a Brantz trip meter fitted in to the Ineos.

Brantz - Home of Historic Rally Equipment - United Kingdom

The Official Brantz brand of Rally Equipment. The Brantz brand of rally equipment offers the complete range of motorsport Tripmeters and Retrotrips for everyone

www.brantz.co.uk

Hello. Can anyone advise colour of vss wire? Thx Ross



[Thirsty2001]

Hello. Can anyone advise colour of vss wire? Thx Ross

Thanks Ross
